MIL-S-49442 (ER)

SC-C-681273 Sealant, Interior

(Copies of specifications, standards, handbooks, drawings, and publications

required by manufacturers in connection with specific acquisition functions should

be obtained from the contracting activity or as directed by the Contracting Officer).

2.2

Other publications. The following document (s) form a part of this

specification to the extent specified herein. The issues of the documents which

are indicated as DoD adopted shall be the issue listed in the current DoDISS and

the supplement thereto, if applicable.

1979 National Fire Code Volume 7 - Electrical

(Application for copies should be addressed to National Fire Protection Association,

International, Battery March Park, Quincy, Ma, 02269).

Heating, Ventilating and Air Conditioning Guide

(Applications for copies should be addressed to American Society of Heating and

Refrigerating Engineers, 345 East 47th Street, New York, N.Y. 10017).

2.3 Order of Procedure. In the event of a conflict between the text of this

specification and the references cited herein, the text of this specification

shall take precedence.

3.1

First Article of production. Unless otherwise specified in the invitation

for bids and contract, the contractor shall furnish one First Article of production

of the shelter facility for approval.

(See 4.3).

3.2 Construction. The Shelter Facility shall be constructed in accordance with

the drawings as listed on DL-C5079125.

3.3 Electrical Installation

3.3.1 Power system wiring and components. Installation and wiring of power

wires and components including cable assemblies, receptacles, switches, meters,

circuit breakers, neon lamps, flourescent lamps, lighting fixtures, distribution

assemble system and wiring components shall be in accordance with the drawings

unless otherwise stated. The completed in-place power distribution system shall

meet the following requirements:

3.3.1.1 Input power. The shop equipment, battery servicing, shelter mounted AN/TSM-

shall be capable of meeting the performance requirements of this specification

133

when operated from any power source having a voltage of 120/208 volts

10%, three

phase, WYE connected, frequency 47 to 63 Hz, 100 ampere service, five (5) wire.
