5.5. 1.13 Sliding or friction surfaces. Surfaces of ways, gibs, driving gears,
traversing and adjusting screws, and other critical, external operating machined
surfaces shall be coated with P-2, grade 2 preservative compound and covered with
greaseproof barrier material. Parts of the machine which are adjustable shall be
locked into place.
5.5.1.14 Bearings and journals. Grease lubricated bearings shall be preserved
with P-11 preservative. Oil lubricated journals shall be filled with lubricating
oil P-13, type I, grade optional.
5.5.1.1: Drive belts and pulleys. Drive belts shall either be removed from the
machine or released from tension. Ferrous metal pulleys shall be coated with
rust-inhibiting primer. Belts removed from the machine shall be packaged in a
waterproof, greaseproof bag and sealed.
5.5.1.16 Electrical wiring system. Exposed ends of wires, plug openings,
sockets, connector plugs, terminals, and openings into switches and junction boxes,
etc. shall be sealed with waterproof tape or cap-plugs, respectively. Electric
cable shall be coiled to a minimum safe diameter and secure with cotton tape or
twine to prevent uncoiling.
5.5.1.17 Closed dial indicators. Closed dial indicators shall be covered with 1
inch thick uncompressed cushioning material and secured in place with waterproof,
pressure sensitive tape. Cushioning materials and tape used shall be
water-resistant, non-dusting and non-corrosive.
5.5.1.13 Drawers and door assemblies. Sliding surfaces of drawer guides shall be
coated with P-11 preservative grease. Interior surfaces of door hinges shall be
lubricated by application of P-10, grade 30 preservative oil. In addition to
mechanical locks or catches incorporated in the machine, secure doors and drawers
with metal strapping or other devices which are suitable for the purpose intended.
Fiberboard pads shall be placed under metal strapping to prevent marring the
surfaces.
5.5.1.19 Closure of openings. Small openings, except vents and louvres installed
for ventilation purposed, shall be sealed with waterproof, pressure sensitive tape.
Large openings shall be covered with waterproof barrier materials. Secure materials
in place with tape specified above. When very large openings are covered, or when
location of openings render coverings vulnerable to puncture, coverings shall be
protected by applying wood, plywood, sheet metal or fiberboard over the materials.
Open ends of all piping and fittings shall be plugged to prevent the entrance of
foreign materials, using pipe fitting, waterproof tape or plastic cap-plugs.
5.5.1.20 Technical data. Technical data furnished with the machine shall be
packaged in a waterproof, greaseproof barrier material and sealed. The package
shall be legibly and clearly marked "TECHNICAL DATA" in bold letters. The package
shall be protected against puncture and abrasion. The data shall be either attached
to the machine with tape, placed in a stowage compartment of the machine, or
positioned in a consolidated box containing accessories or disassembled components.
5.5.1.21 Consolidated packaging. Packaged accessories, maintenance tools, and
small disassembled components shall be consolidated and placed in drawers and
stowage compartments of the machine. When it is not feasible to stow parts as
specified above, place parts in weather-resistant fiberboard box or boxes of
sufficient strength to handle weight inside. Large bulky disassembled components
shall be packed as specified (see 5.6.1.1).
